应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 导体电阻Ω/km | 参考载流量 A |
| 1 | 2X16mm²+1X16mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 30.0 | 1.21 | 63 |
| 2 | 2X25mm²+1X25mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 34.0 | 0.780 | 100 |
| 3 | 2X35mm²+1X25mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 36.0 | 0.554 | 125 |
| 4 | 2X50mm²+1X25mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 38.0 | 0.386 | 150 |
| 5 | 2X70mm²+1X25mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 40.5 | 0.272 | 200 |
| 6 | 2X80mm²+1X25mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 42.0 | 0.238 | 250 |
| 7 | 2X95mm²+1X25mm²+2X4mm²+2P（2X0.75mm²）+P(8X0.75mm²） | 44.0 | 0.206 | 300 |
