应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X2X0.22mm² | 7.5 | 28.5 | 63 |
| 2 | 3X2X0.22mm² | 7.9 | 36.1 | 75 |
| 3 | 4X2X0.22mm² | 8.7 | 44.3 | 93 |
| 4 | 5X2X0.22mm² | 9.4 | 52.7 | 108 |
| 5 | 6X2X0.22mm² | 10.3 | 61.2 | 127 |
| 6 | 8X2X0.22mm² | 11.0 | 76.0 | 152 |
| 7 | 10X2X0.22mm² | 12.9 | 93.7 | 190 |
| 8 | 2X2X0.34mm² | 7.8 | 36.6 | 73 |
| 9 | 3X2X0.34mm² | 8.3 | 47.7 | 89 |
| 10 | 4X2X0.34mm² | 9.2 | 59.5 | 111 |
| 11 | 5X2X0.34mm² | 10.1 | 71.5 | 134 |
| 12 | 6X2X0.34mm² | 10.8 | 83.7 | 153 |
| 13 | 8X2X0.34mm² | 11.8 | 105.5 | 191 |
| 14 | 10X2X0.34mm² | 13.6 | 130.5 | 233 |
| 15 | 2X2X0.5mm² | 8.6 | 48.0 | 89 |
| 16 | 3X2X0.5mm² | 9.3 | 63.8 | 115 |
| 17 | 4X2X0.5mm² | 10.2 | 80.5 | 143 |
| 18 | 5X2X0.5mm² | 11.3 | 97.3 | 173 |
| 19 | 6X2X0.5mm² | 12.1 | 86.1 | 162 |
| 20 | 8X2X0.5mm² | 13.0 | 145.5 | 243 |
| 21 | 10X2X0.5mm² | 15.4 | 180.5 | 310 |
| 22 | 2X2X0.75mm² | 9.5 | 60.2 | 109 |
| 23 | 3X2X0.75mm² | 10.3 | 81.1 | 141 |
| 24 | 4X2X0.75mm² | 11.3 | 102.9 | 177 |
| 25 | 2X2X1.0mm² | 11.0 | 73.2 | 139 |
| 26 | 3X2X1.0mm² | 11.6 | 99.2 | 175 |
| 27 | 4X2X1.0mm² | 12.6 | 126.3 | 213 |
