| 序号 | 型号规格 | 导体材质 | 绝缘材质 | 绝缘平均厚度 | 绝缘最薄厚度 | 绝缘外径 | 导体电阻at20℃（Ω/km） |
| 1 | H07Z1-K 1.5mm² | 裸铜丝 | LSZH | 0.44mm | 0.70mm | 3.0mm | 13.3 |
| 2 | H07Z1-K 2.5mm² | 裸铜丝 | LSZH | 0.62mm | 0.80mm | 3.7mm | 7.98 |
| 3 | H07Z1-K 4.0mm² | 裸铜丝 | LSZH | 0.62mm | 0.80mm | 4.2mm | 4.95 |
| 4 | H07Z1-K 6.0mm² | 裸铜丝 | LSZH | 0.62mm | 0.80mm | 5.25mm | 3.30 |
| 5 | H07Z1-K 10mm² | 裸铜丝 | LSZH | 0.80mm | 1.00mm | 6.7mm | 1.91 |
| 6 | H07Z1-K 16mm² | 裸铜丝 | LSZH | 0.80mm | 1.00mm | 8mm | 1.21 |
| 7 | H07Z1-K 25mm² | 裸铜丝 | LSZH | 0.98mm | 1.20mm | 10mm | 0.780 |
| 8 | H07Z1-K 35mm² | 裸铜丝 | LSZH | 0.98mm | 1.20mm | 11.3mm | 0.554 |
| 9 | H07Z1-K 50mm² | 裸铜丝 | LSZH | 1.16mm | 1.40mm | 13.5mm | 0.386 |
| 10 | H07Z1-K 70mm² | 裸铜丝 | LSZH | 1.16mm | 1.40mm | 15.5mm | 0.272 |
| 11 | H07Z1-K 95mm² | 裸铜丝 | LSZH | 1.34mm | 1.60mm | 17.8mm | 0.206 |
| 12 | H07Z1-K 120mm² | 裸铜丝 | LSZH | 1.34mm | 1.60mm | 20.1mm | 0.161 |
| 13 | H07Z1-K 150mm² | 裸铜丝 | LSZH | 1.52mm | 1.80mm | 22.5mm | 0.129 |
| 14 | H07Z1-K 185mm² | 裸铜丝 | LSZH | 1.70mm | 2.00mm | 25.3mm | 0.106 |
| 15 | H07Z1-K 240mm² | 裸铜丝 | LSZH | 1.88mm | 2.20mm | 27.8mm | 0.0801 |
