应用范围：
| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 4G1.5mm² | 10.5 | 87 | 230 |
| 2 | 4G2.5mm² | 11.8 | 133 | 300 |
| 3 | 4G4mm² | 13.3 | 213 | 485 |
| 4 | 4G6mm² | 14.9 | 298 | 630 |
| 5 | 4G10mm² | 17.7 | 460 | 860 |
| 6 | 4G16mm² | 21.5 | 707 | 1290 |
| 7 | 4G25mm² | 26.3 | 1100 | 1860 |
| 8 | 4G35mm² | 29.7 | 1542 | 2610 |
| 9 | 4G50mm² | 34.1 | 2206 | 2950 |
| 10 | 4G70mm² | 40.9 | 3002 | 3950 |
| 11 | 4G95mm² | 45.4 | 4004 | 5300 |
| 12 | 4G120mm² | 49.8 | 5108 | 6600 |
| 13 | 4G150mm² | 56.1 | 6225 | 7043 |
| 14 | 4G185mm² | 61.4 | 7568 | 8384 |
| 15 | 4G240mm² | 67.9 | 9940 | 12150 |
| 16 | 3X1.5mm²+3G0.25mm² | 11.4 | 88 | 140 |
| 17 | 3X2.5mm²+3G0.5mm² | 12.9 | 130 | 220 |
| 18 | 3X4mm²+3G0.75mm² | 13.6 | 224 | 323 |
| 19 | 3X6mm²+3G1.0mm² | 15.2 | 276 | 420 |
| 20 | 3X10mm²+3G1.5mm² | 17.4 | 511 | 615 |
| 21 | 3X16mm²+3G2.5mm² | 20.0 | 751 | 819 |
| 22 | 3X25mm²+3G4mm² | 24.3 | 1204 | 1325 |
| 23 | 3X35mm²+3G6mm² | 27.5 | 1535 | 1718 |
| 24 | 3X50mm²+3G10mm² | 31.1 | 2156 | 2399 |
| 25 | 3X70mm²+3G10mm² | 37.1 | 2980 | 3056 |
| 26 | 3X95mm²+3G16mm² | 40.0 | 3953 | 4162 |
| 27 | 3X120mm²+3G16mm² | 42.6 | 4836 | 5074 |
| 28 | 3X150mm²+3G25mm² | 50.0 | 5412 | 6128 |
| 29 | 3X185mm²+3G35mm² | 55.6 | 7077 | 7820 |
