| 编号 | 芯数 X 标称截面mm² | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 1 | 2X0.34mm² | 4.9 | 6.1 | 25 |
| 2 | 3X0.34mm² | 5.1 | 9.2 | 30 |
| 3 | 4X0.34mm² | 5.5 | 12.2 | 36 |
| 4 | 5X0.34mm² | 5.9 | 15.3 | 43 |
| 5 | 2X0.5mm² | 5.8 | 9.1 | 39 |
| 6 | 3G0.5mm² | 6.1 | 13.6 | 46 |
| 7 | 4G0.5mm² | 6.5 | 18.1 | 56 |
| 8 | 5G0.5mm² | 7.1 | 22.7 | 67 |
| 9 | 7G0.5mm² | 7.8 | 31.8 | 85 |
| 10 | 10G0.5mm² | 9.8 | 45.4 | 124 |
| 11 | 2X0.75mm² | 6.2 | 13.8 | 48 |
| 12 | 3G0.75mm² | 6.5 | 20.7 | 57 |
| 13 | 4G0.75mm² | 7.0 | 27.6 | 70 |
| 14 | 2X1.0mm² | 6.7 | 18.4 | 58 |
| 15 | 3G1.0mm² | 7.1 | 27.6 | 70 |
| 16 | 4G1.0mm² | 7.6 | 36.9 | 87 |
| 17 | 2X1.5mm² | 7.5 | 27.6 | 77 |
| 18 | 3G1.5mm² | 7.9 | 41.5 | 95 |
| 19 | 4G1.5mm² | 8.8 | 55.3 | 121 |
| 20 | 2X2.5mm² | 9.0 | 46.1 | 118 |
| 21 | 3G2.5mm² | 9.7 | 69.1 | 151 |
| 22 | 4G2.5mm² | 10.8 | 92.2 | 192 |
