应用范围：
| 物料编号 | 芯数 X 标称截面AWG | 电缆外径约mm | 铜重量约kg/km | 电缆重量约kg/km |
| 2X28AWG | 3.4 | 1.5 | 13 | |
| 3X28AWG | 3.5 | 2.2 | 15 | |
| 4X28AWG | 3.8 | 2.9 | 17 | |
| 5X28AWG | 4.0 | 3.6 | 20 | |
| 6X28AWG | 4.3 | 4.4 | 23 | |
| 7X28AWG | 4.3 | 5.1 | 23 | |
| 8X28AWG | 4.6 | 5.8 | 26 | |
| 10X28AWG | 5.2 | 7.3 | 34 | |
| 12X28AWG | 5.3 | 8.7 | 37 | |
| 14X28AWG | 5.6 | 10.2 | 41 | |
| 16X28AWG | 6.0 | 11.6 | 48 | |
| 18X28AWG | 6.3 | 13.1 | 52 | |
| 20X28AWG | 6.6 | 14.5 | 57 | |
| 25X28AWG | 7.4 | 18.1 | 72 | |
| 30X28AWG | 7.8 | 21.8 | 81 | |
| 32X28AWG | 8.0 | 23.2 | 87 | |
| 36X28AWG | 8.5 | 26.1 | 98 | |
| 37X28AWG | 8.5 | 26.9 | 98 | |
| 40X28AWG | 8.8 | 29.0 | 105 | |
| 50X28AWG | 10.0 | 36.3 | 135 | |
| 2X26AWG | 3.6 | 2.6 | 15 | |
| 3X26AWG | 3.8 | 3.9 | 18 | |
| 4X26AWG | 4.0 | 5.2 | 21 | |
| 5X26AWG | 4.3 | 6.5 | 24 | |
| 6X26AWG | 4.6 | 7.7 | 28 | |
| 7X26AWG | 4.6 | 9.0 | 29 | |
| 8X26AWG | 4.9 | 10.3 | 34 | |
| 10X26AWG | 5.6 | 12.9 | 43 | |
| 12X26AWG | 5.8 | 15.5 | 47 | |
| 14X26AWG | 6.2 | 18.1 | 55 | |
| 16X26AWG | 6.5 | 20.6 | 61 | |
| 18X26AWG | 6.8 | 23.2 | 68 | |
| 20X26AWG | 7.1 | 25.8 | 74 | |
| 25X26AWG | 8.0 | 32.3 | 94 | |
| 30X26AWG | 8.4 | 38.7 | 107 | |
| 32X26AWG | 8.7 | 41.3 | 114 | |
| 36X26AWG | 9.2 | 46.4 | 128 | |
| 37X26AWG | 9.2 | 47.7 | 129 | |
| 40X26AWG | 9.5 | 51.6 | 138 | |
| 50X26AWG | 10.8 | 64.5 | 177 | |
| 2X24AWG | 3.8 | 4.1 | 18 | |
| 3X24AWG | 4.0 | 6.1 | 21 | |
| 4X24AWG | 4.3 | 8.1 | 25 | |
| 5X24AWG | 4.6 | 10.1 | 30 | |
| 6X24AWG | 4.9 | 12.2 | 35 | |
| 7X24AWG | 4.9 | 14.2 | 37 | |
| 8X24AWG | 5.2 | 16.2 | 42 | |
| 10X24AWG | 6.2 | 20.3 | 57 | |
| 12X24AWG | 6.4 | 24.3 | 63 | |
| 14X24AWG | 6.7 | 28.4 | 70 | |
| 16X24AWG | 7.0 | 32.4 | 78 | |
| 18X24AWG | 7.3 | 36.5 | 86 | |
| 20X24AWG | 7.8 | 40.5 | 98 | |
| 25X24AWG | 8.6 | 50.7 | 120 | |
| 30X24AWG | 9.3 | 60.8 | 141 | |
| 32X24AWG | 9.6 | 64.9 | 151 | |
| 36X24AWG | 9.9 | 73.0 | 165 | |
| 37X24AWG | 9.9 | 75.0 | 166 | |
| 40X24AWG | 10.4 | 81.1 | 183 | |
| 50X24AWG | 12.1 | 101.4 | 238 | |
| 2X22AWG | 4.2 | 6.3 | 23 | |
| 3X22AWG | 4.4 | 9.4 | 28 | |
| 4X22AWG | 4.7 | 12.5 | 34 | |
| 5X22AWG | 5.1 | 15.7 | 40 | |
| 6X22AWG | 5.5 | 18.8 | 47 | |
| 7X22AWG | 5.5 | 21.9 | 50 | |
| 8X22AWG | 5.9 | 25.1 | 57 | |
| 10X22AWG | 7.0 | 31.3 | 77 | |
| 12X22AWG | 7.2 | 37.6 | 86 | |
| 14X22AWG | 7.5 | 43.9 | 97 | |
| 16X22AWG | 8.1 | 50.1 | 111 | |
| 18X22AWG | 8.5 | 56.4 | 123 | |
| 20X22AWG | 8.9 | 62.7 | 136 | |
| 25X22AWG | 10.0 | 78.3 | 171 | |
| 30X22AWG | 10.7 | 94.0 | 200 | |
| 36X22AWG | 11.7 | 112.8 | 239 | |
| 37X22AWG | 11.9 | 115.9 | 246 | |
| 40X22AWG | 12.3 | 125.3 | 265 | |
| 2X20AWG | 4.8 | 9.6 | 31 | |
| 3X20AWG | 5.0 | 14.4 | 38 | |
| 4X20AWG | 5.5 | 19.2 | 47 | |
| 5X20AWG | 5.9 | 24.0 | 57 | |
| 6X20AWG | 6.4 | 28.8 | 67 | |
| 7X20AWG | 6.4 | 33.5 | 71 | |
| 8X20AWG | 7.1 | 38.3 | 85 | |
| 10X20AWG | 8.4 | 47.9 | 114 | |
| 12X20AWG | 8.6 | 57.5 | 127 | |
| 14X20AWG | 9.3 | 67.1 | 146 | |
| 16X20AWG | 9.7 | 76.7 | 164 | |
| 18X20AWG | 10.4 | 86.3 | 186 | |
| 20X20AWG | 10.9 | 95.8 | 205 | |
| 25X20AWG | 12.4 | 119.8 | 262 | |
| 30X20AWG | 13.1 | 143.8 | 301 | |
| 37X20AWG | 14.2 | 177.3 | 362 | |
| 40X20AWG | 14.7 | 191.7 | 389 | |
| 2X18AWG | 5.2 | 15.1 | 40 | |
| 3X18AWG | 5.5 | 22.7 | 50 | |
| 4X18AWG | 5.9 | 30.2 | 62 | |
| 5X18AWG | 6.7 | 37.8 | 78 | |
| 6X18AWG | 7.2 | 45.3 | 92 | |
| 7X18AWG | 7.2 | 52.9 | 99 | |
| 8X18AWG | 7.9 | 60.5 | 117 | |
| 10X18AWG | 9.4 | 75.6 | 155 | |
| 12X18AWG | 9.7 | 90.7 | 174 | |
| 16X18AWG | 10.9 | 120.9 | 226 | |
| 18X18AWG | 11.8 | 136.0 | 260 | |
| 20X18AWG | 12.3 | 151.1 | 287 | |
| 25X18AWG | 13.8 | 188.9 | 359 | |
| 2X16AWG | 6.4 | 23.4 | 62 | |
| 3X16AWG | 6.8 | 35.1 | 77 | |
| 4X16AWG | 7.6 | 46.8 | 100 | |
| 5X16AWG | 8.3 | 58.5 | 121 | |
| 2X14AWG | 7.2 | 36.9 | 84 | |
| 3X14AWG | 7.8 | 55.3 | 111 | |
| 4X14AWG | 8.6 | 73.8 | 139 | |
| 5X14AWG | 9.6 | 92.2 | 174 |
